2022 Felt IA Advanced, Rim Brake 105 - Midnight - Geo

Felt
Availability:
Due to Covid-19 limitations some products might not be in stock. Please call or email to confirm availability.
$3,549.00
(No reviews yet)
Weight:
45.00 LBS
Width:
58.00 (in)
Height:
10.00 (in)
Depth:
32.00 (in)
Current Stock:
Adding to cart… The item has been added

OUR MOST AERO BIKE. EVER

Our very first bike was made for one of the greatest triathletes in history—Paula Newby-Fraser—who rode her stealth black Felt B2 to multiple world championship victories. Since then, we’ve never stopped pursuing the ideal triathlon racing machine. The IA is the culmination of 30 years of iterative design and painstaking development, and its results at the highest level of competition speak for themselves. So we can tell you that the IA is the most aerodynamic bike in the world. We can also say that it’s the best-handling triathlon bike on the planet. But what we should really mention is that the IA won the Kona World Championship a staggering six times in a row, and it holds both bike and overall course records across the lava fields of Hawaii. So, really, what else do you need to know?

  • Advanced-level carbon layup
  • Shimano 105 rim brakes
  • Tubeless-ready aluminum wheels

AERODYNAMICS

Every racecourse is different, with varying elevation gains, road curvature, and, of course, an endless variety of wind, both in terms of velocity and direction. After endless simulated modeling, wind tunnel testing, and real-world riding of prototypes, countless new designs were scrutinized, updated, and tested again, the cycle repeating anew. The result is a bike worthy of carrying on the legendary IA name, one also featuring the improved performance that disc brakes bring to the riding experience. It's not merely fast in a straight line-it's faster in all conditions.

DISC BRAKES & THRU-AXLES

Disc brakes are the best means of controlling a bicycle. Period. Plus, they perform better in adverse weather conditions. Wherever the road takes you, and in whatever conditions you find yourself, the disc brake-equipped IA gives you the confidence to tackle any racecourse. To accommodate the added stopping forces provided by disc brakes, the IA features thru-axles rather than traditional quick-release skewers. It's a proven design that provides a more secure interface between the bicycle frame and the wheel, which also enhances the stiffness of the frame-and-wheel connection. We also offer a version of the IA with rim brakes for athletes who still prefer that classic feel.

STORAGE SOLUTIONS

The IA comes equipped with Felt's latest top tube storage solution, the integrated CALpac 2.0. This storage unit features ample space for all of the riding essentials to which a rider needs quick and easy access. Likewise, the IA includes the BTSpac storage device, located behind the seat tube. This unit is ideal for a flat tire repair kit and/or on-the-go tool kit, or any other items that a rider doesn't require while pedaling on the bike. It's shape has been aerodynamically optimized for the IA, meaning that it creates no penalty in terms of aerodynamic drag.

Geometry

Click for Geometry

VERSION:
IA | 8
MODEL:
IA | Advanced, Rim Brake | 105
PRICE:
$ 2,999
MODEL CODE:
FB-20A-IAX16-TA-FA
SIZES:
5 | 48, 51, 54, 56, 58cm
FRAME TECHNOLOGIES:
MMC / InsideOut / Felt CALpac 2.0 top tube storage with Felt AEROpac 2.0 top tube storage cover
BRAKE TYPE, REAR:
Rim, Direct Mount | chainstay, under bottom bracket
DERAILLEUR HANGER TYPE, REAR:
Standard Mount | QR 130 TT/TRI, integrated with frame, non-replaceable
PROTECTOR TYPE:
Steerer stop integration for head tube protection / Felt ChainPlate for chain suck protection / Clear vinyl for chain slap protection
SEAT POST / CLAMP TYPE:
Felt Aero TRI InternaLoc 1.0 | integrated with titanium bolts
TIRE MAX (CLEARANCE):
28mm (4mm)
HEADSET:
IS (IS-2)
AXLE, REAR:
QR 130, horizontal with integrated adjusters
BRAKE TYPE, FRONT:
Rim, Standard Mount
HEADSET SPECIFICATION:
Top Cap: stem integrated / Top Cover: stem integrated / Top Cover (standard stem): Felt integrated aluminum / Bearings: FSA integrated sealed cartridge, MR122 / Spacers: - / Compression Device: Felt for carbon steerer tube / Compression Ring: FSA H21
SHIFTERS:
microSHIFT A11, TRI/TT
DERAILLEUR, REAR:
Shimano 105 R7000, short cage
BOTTOM BRACKET:
Shimano RS500
CHAIN:
Shimano 105 HG601
BRAKE LEVERS:
Tektro TL720
WHEELS:
Devox WheelRRS.A1 with Shimano hubs | 24/19
TIRE, REAR:
FB-21A-IAX16RB-MT-FA
RIMS:
Aluminum
RIM WIDTH, INSIDE:
19mm
HUB, REAR:
Shimano RS400 | J-Bend, 28h, QR 130, 11-speed
NIPPLES:
Brass, black
STEM:
Felt Dagger 31.8 | SuperLite aluminum
HANDLEBAR CLAMP DIAMETER:
31.8mm
STEM CLAMP DIAMETER:
31.8mm
STEM LENGTH:
110mm
SEATPOST:
Felt Aero TRI IL 1.0 VM | UHC Advanced carbon fiber
SEATPOST OFFSET:
0mm
SEATPOST PARTS & TECHNOLOGIES:
Integrated / Compliance Channels with aero covers / Aero TRI InternaLoc 1.0 seatpost clamping system / Patented VariMount (VM) saddle rail clamping system
WEIGHT:
21.67 lb, 9.85 kg
SPECIFICATION DISCLAIMER:
Specifications subject to change without notice.
SERIES:
IAX (1.0)
MARKET:
Global
FINISH:
Midnight (Geo)
MODEL # M3:
BBICA10
FRAME:
Felt IntegratedAero x 1.0 | UHC Advanced + TeXtreme carbon fiber
BOTTOM BRACKET TYPE:
Threaded | BSA 68mm
DERAILLEUR HANGER TYPE, FRONT:
Brazed-On | integrated backup plate, non-replaceable, aluminum
HEAD-TUBE TYPE:
Felt Aero | 1.125";ROUTING TYPE=Internal | convertible for electronic or mechanical"
WHEEL TYPE:
700c
FORK:
Felt IntegratedAero x 1.0 | UHC Advanced + TeXtreme carbon fiber
AXLE, FRONT:
QR 100
FORK TECHNOLOGIES:
Monocoque construction / Integrated crown race
FORK OFFSET:
48, 51cm: 50mm / 54, 56, 58cm: 45mm
DRIVETRAIN:
2x11-speed
DERAILLEUR, FRONT:
Shimano 105 R7000, braze-on
CRANK:
Shimano 105 R7000, 52/36T
CASSETTE:
Shimano 105 R7000, 11-28T
CRANK LENGTH:
48, 51cm: 165mm / 54, 56cm: 170mm / 58cm: 172.5mm /
BRAKE CALIPERS:
Front: Shimano 105 R7000 dual-pivot caliper / Rear: Shimano 105 R7010-R under bottom bracket mount caliper
TIRES:
Continental Grand Sport Race, 700x25c
TIRE COMPATIBILITY:
Tubeless Compatible
RIM DEPTH:
24mm
HUB, FRONT:
Shimano RS400 | J-Bend, 28h, QR 100
SPOKES:
J-Bend, 2.0, stainless steel, black
HANDLEBAR:
Basebar: Devox Bayonet 3.1 | SuperLite aluminum / Extensions: Devox Ergomod | aluminum
GRIPS / TAPE:
Felt EVA arm pads with anti-microbial cover and Felt Gel tape
HANDLEBAR WIDTH:
48, 51cm: 39cm / 54, 56, 58cm: 42cm
STEM ANGLE:
-6°
STEM PARTS & TECHNOLOGIES:
Integrated / Integrated top cap / Integrated headset top cover / Integrated cable routing
SADDLE:
ISM PS1.1
SEATPOST LENGTH:
300mm
EXTRAS:
Felt BTSpac seat tube storage box / Compliance Channel aero seatpost covers / Carbon assembly paste
WEIGHT DISCLAIMER:
The most accurate way to determine a product's weight is to have your local dealer weigh it for you. Because we understand that weight is an important metric, we strive to list it when possible. When listed, weight is based on a single sample in a sp
