2024 Bianchi e-Omnia C Type DEORE 10SP

FRAME

e-Omnia C Type Step Thru chain drive ALU, 2 size: SM, MD, LG (45-50-55), Ready to fix the chainguard, Post mount 180mm disc brake type, Ready to fix rear kyckstand, custom rearcarrier integrated in the frame, Set dropout (sx+dx) QR 135mm external deraille

FORK

SR SUNTOUR XCM34 BOOST LOR DS 29" TRAVEL 100MM

HEADSET

Fsa NO.55R/558 1.5"

SHIFTERS

Shimano Deore SL-M4100-R, 10sp

REAR DERAILLEUR

Shimano RD-M5120, DEORE, SGS 10sp, SHADOW DESIGN

CRANKSET

FSA METROPOLIS ALLOY E-BIKE SPECIFIC, CRANK LENGTH 170MM, ISIS BB AXLE, W/FSA 38T STEEL MEGATOOTH CHAINRING

BOTTOM BRACKET

Included w/motor unit

CHAIN

Kmc e10S NPBK Anti-Rust 1/2" x 11/128" EPT

CASSETTE

Shimano DEORE CS-M4100-10, 11-42T

BRAKES

SHIMANO BR-MT200, W/180MM FRONT & REAR ADAPTERS, RESIN PAD

ROTOR

Shimano SM-RT10, diam. 180mm

WHEELS

VELOMANN EBIKE MAXX 29" - 622X25C

REARHUB

FORMULA CL-1422 CENTER LOCK

FRONTHUB

SHIMANO HB-MT400-B CENTER LOCK, 15X110MM TA

TIRE

SCHWALBE MARATHON E-PLUS 55-622 28X2.15

STEM

Velomann 35/31.8mm, lenght: 95mm for Kiox mount

HANDLEBAR

Velomann AL6061, diam. 31.8mm, width 630mm, Rise 34mm, Backsweep 41°

SEATPOST

Velomann, lenght 350mm-15/17'' and 400mm-19/21'', diam.31,6mm, 0mm seatback, AL2014 shaft

SADDLE

Velomann A038UE0 Unisex, Rail Elastomer, black steel rail, 256x220

GRIPS

HERRMANS LUNA LOCK

MOTOR

BOSCH PERFORMANCE LINE CX 250W 85NM

BATTERY

BOSCH POWERTUBE 625WH

MUDGUARDS

SKS PET MUDGUARDS A65 R

FRONTLIGHT

INTEGRATED CUSTOM FRONT AND SIDE LIGHT MADE W/SPANNINGA

REARLIGHT

Spanninga integrated rear lights

REARCARRIER

custom rear carrier integrated into the frame design

KICKSTAND

VELOMANN R78 KING EVO REAR MAX 35KG

Click for Geometry
