2024 BMC Teammachine SLR FIVE - Black / White
BMC
$3,199.00
(No reviews yet)
Write a Review
BMC
2024 BMC Teammachine SLR FIVE - Black / White
The Teammachine SLR, legendary performance in a widely accessible package. Its Teammachine SLR Carbon frame and fork have been designed using TCC Race Technology, offers Stealth Dropouts and internal cable routing. Introducing the carbon Teammachine SLR range, the Teammachine SLR FIVE has a Shimano 105 groupset with PRD23 wheelset and a compact drop bar.
Specification
- SHIMANO 105 Drivetrain
- PRD23 Wheels
- Integrated Cable Routing and Carbon D-Shape Seatpost
Accelerated Composites Evolution Technology + (ACE+)
ACE+ not only generates thousands of virtual frameset prototypes to satisfy Stiffness, Weight and Compliance targets, but now also includes a fourth key factor, Aerodynamics.
Aerocore Design
The superlight carbon cages seamlessly integrate with the reshaped down tube and seat tube, resulting in significant drag reduction when used with bottles. Available as an ugrade on the Teammachine SLR line.
D-Shape Seatpost
The latest evolution of our signature D-Shape seatpost: this optimized design features the minimalist saddle clamp, resulting in lower weight; while still retaining excellent aerodynamic performance and compliance.
Comfort Is Speed
The new Teammachine SLR is more compliant than ever, thanks to the latest evolution of the Tuned Compliance Concept (TCC) technology.
- Frame:
- Teammachine SLR Carbon with Aerocore Design | Stealth Dropout Design | TCC Race Compliance Level | PF86 Bottom Bracket | Flat Mount Disc | 12x142mm Thru-Axle | Optimized for Aerocore Bottle Cages
- Fork:
- Teammachine SLR Carbon | TCC Race Compliance Level | Internal Cable Routing | Flat Mount Disc | Stealth Dropout Design | 12x100mm Thru-Axle
- Handlebar:
- BMC RAB 02 - Ergo Top Shape - Compact Bend
- Seatpost:
- Teammachine SLR Carbon D-Shaped Seatpost | 15mm Offset
- Saddle:
- Fizik Antares R7
- Gears:
- 2x12
- Crankset:
- SHIMANO 105 FC-R7100 50-34T
- Cassette:
- SHIMANO 105 CS-R7000 11-32T
- Chain:
- SHIMANO 105 CN-M6100 12spd
- Front Derailleur:
- SHIMANO 105 FD-R7100
- Rear Derailleur:
- SHIMANO 105 RD-R7100
- Shifters:
- SHIMANO 105 ST-R7120
- Brake Levers / Calipers:
- SHIMANO 105 BR-R7170
- Rotors:
- SHIMANO SM-RT70 160 / 160 mm - Centerlock
- Rims:
- PRD23 - 23mm
- Hubs (F/R):
- CL-712 (F)/RXC-142S (R) - Thru Axle
- Tires:
- Pirelli P7 Sport, 26mm
- Tire Clearance:
- 30mm (Measured Width)
- ASTM Classification:
- Level 1
- Weight Limit:
- 110 Kg
- Stem:
- BMC RSM01
