2025 Salsa Rangefinder Advent X 27.5+ - Silver

Rangefinder Advent X 27.5+ is a hardtail trail mountain bike that delivers happiness on every stretch of dirt. Our stable trail geometry is designed for a comfortable, confident ride and a 120 mm suspension fork smooths out rocks and roots. Nimble 27.5" wheels with 2.8"-wide tires deliver great grip on a wide range of trail surfaces so you can trust your line on challenging terrain. The microSHIFT Advent X components strike the perfect balance of durability, weight, and ease of use.

WARNING:

This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

SPECIFICATIONS:

Headset:

FSA Orbit NO.57B 1.5 ZS

Seatpost:

Salsa Guide 30.9, 0 offset

Stem:

Salsa Guide 31.8, 60 mm, 6d

Grips/Bar Tape:

Salsa File Tread

Saddle:

WTB Volt Medium, Steel, 142 x 265 mm

Handlebar:

Salsa Salt Flat 31.8, 750 mm width XS-SM; Salsa Rustler 31.8, 800 mm width M-XL

Rear Derailleur:

microSHIFT Advent X M6205

Cassette:

microSHIFT Advent X H104 11-48t, 10-speed

Chain:

Shimano HG54

Crankset:

FSA Alpha Drive, 30t, FSA 124.5 mm bottom bracket

Shifter:

microSHIFT Advent X M9605

Brake Levers:

Shimano MT200 OR Tektro M520

Brake Calipers:

Shimano MT200 OR Tektro M520

Rotors:

Shimano RT10 Center Lock rotors (160 mm)

Front Wheel:

Shimano MT400 Center Lock 15 x 110 mm TA hub, WTB ST i40 32h 27.5" rim

Rear Wheel:

Shimano MT200 Center Lock 10 x 141 mm QR hub, WTB ST i40 32h 27.5" rim

Front Tire:

Maxxis Rekon 27.5 x 2.8", EXO, Wire Bead (not tubeless compatible)

Rear Tire:

Maxxis Rekon 27.5 x 2.8", EXO, Wire Bead (not tubeless compatible)

Complete Bike:

33 lb (with tubes, no pedals) for Medium

Frame:

Rangefinder Aluminum

Color:

Silver

Suspension Fork:

SR Suntour XCM32 Boost, Coil, NLO, DS, 120 mm

KEY FEATURES:

On-Bike Storage

• Adventures require gear and riders should get to choose whether they carry it on their bike or on their body

ADDITIONAL FEATURES:

6061-T6 Aluminum Tube Set

A blend of our proprietary, top-shelf 6061-T6 double- and triple-butted tubing creates a light, responsive, and durable frame with great trail feel

Rangefinder Trail Geometry

Rangefinder's long top tube, short stem, and 439 mm chainstays provide a stable ride to keep you in control on steep and technical terrain

120 mm of Front Suspension Travel

A 120 mm fork soaks up the trail and a thru-axle keeps the front end stiff for precise handling

Cargo Capacity

The Rangefinder frame has two bottle cages on the inside of the frame, an accessory mount on the underside of the down tube, and top tube mounts for use with our EXP Series Direct-Mount Top Tube Bag. Rear rack mounting bosses are also included at the dropouts, and with the addition of a 35.0mm Rack-Lock seatpost collar, a rear rack can be fitted

Full-Length Cable Routing

Rangefinder can fit both 29" (maximum of 29 x 2.6") and 27.5+ (27.5 x 2.8-3.0") wheels and tires

Click for Geometrical Chart

SUPPORTIVE DOCUMENTS:

Click for Bicycle Owner's Manual

Click for ASTM 3 Framesheet

Click for ASTM Riding Conditions Classifications
