2025 Salsa Rangefinder Deore 10 29 - Ceramic White

Salsa
Availability:
Most in stock items ship within 1-3 business days
$20,603.28
(No reviews yet)
Weight:
45.00 LBS
Width:
58.00 (in)
Height:
10.00 (in)
Depth:
32.00 (in)
Current Stock:
Adding to cart… The item has been added

Rangefinder Deore 10 29 is the perfect introduction to your local trails. Its frame design keeps you feeling in control as you build your skills. The components reinforce your confidence, with a 120mm fork to soak up trail chatter, 29 x 2.6" wheels and tires to roll over obstacles, and a Shimano Deore 1 x 10-speed drivetrain. Cargo mounts on the frame let you carry more for longer off-road adventures. All together, Rangefinder makes mountain biking more accessible with smart spec and a price point that leaves plenty of room in your budget.

WARNING:

This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

SPECIFICATIONS:

Headset:

FSA Orbit NO.57B 1.5 ZS

Seatpost:

Salsa Guide 30.9, 0 offset

Stem:

Salsa Guide 31.8, 60 mm, 6d

Grips/Bar Tape:

Salsa File Tread

Saddle:

WTB Volt Medium, Steel, 142 x 265 mm

Handlebar:

Salsa Salt Flat 31.8, 750 mm width XS-SM; Salsa Rustler 31.8, 800 mm width M-XL

Rear Derailleur:

Shimano Deore M5120 SGS

Cassette:

Shimano Deore M4100 11-46t, 10-speed

Chain:

Shimano HG54

Crankset:

FSA Alpha Drive, 30t, FSA 124.5 mm bottom bracket

Shifter:

Shimano Deore M4100

Brake Calipers:

Shimano MT200

Rotors:

Shimano RT10 (Center Lock, 160 mm)

Front Wheel:

Shimano TC500-B 15 x 110 mm TA hub, WTB ST i30 32h 29" rim

Rear Wheel:

Shimano MT200-B 10 x 141 mm QR hub, WTB ST i30 32h 29" rim

Front Tire:

Maxxis Rekon 29 x 2.6", EXO, Wire Bead

Rear Tire:

Maxxis Rekon 29 x 2.6", EXO, Wire Bead

Complete Bike:

32 lbs 8 oz (size Medium, with tubes, no pedals)

Frame:

Rangefinder

Color:

Ceramic White

Fork:

SR Suntour XCM32 Coil Boost NLO DS, 120mm

KEY FEATURES:

On-Bike Storage

  • Adventures require gear and riders should get to choose whether they carry it on their bike or on their body

ADDITIONAL FEATURES:

6061-T6 Aluminum Tube Set

A blend of our proprietary, top-shelf 6061-T6 double- and triple-butted tubing creates a light, responsive, and durable frame with great trail feel

Rangefinder Trail Geometry

Rangefinder's long top tube, short stem, and 439 mm chainstays provide a stable ride to keep you in control on steep and technical terrain

120mm front suspension travel

A 120 mm fork soaks up the trail and a thru-axle keeps the front end stiff for precise handling

Cargo Capacity

The Rangefinder frame has two bottle cages on the inside of the frame, an accessory mount on the underside of the down tube, and top tube mounts for use with our EXP-R Series Trillium Top Tube Bag

Full-length Cable Housing

Full-length housing improves shifting in poor conditions and increases the time between maintenance intervals

Dual Wheel Size Compatiblity

Rangefinder can fit both 29" (maximum of 29 x 2.6") and 27.5+ (27.5 x 2.8-3.0") wheels and tires

Click for Geometrical Chart

SUPPORTIVE DOCUMENTS:

Click for Bicycle Owner's Manual

Click for ASTM 3 Framesheet

Click for ASTM Riding Conditions Classifications

Frame Suspension Fork Length (Travel):
100-130 mm
Frame Fork Offset:
46 mm
Frame Rear Spacing:
141 x 10 mm QR
Frame Rear Brake (Rotor):
74 mm post mount (160-180 mm rotor)
Frame Headset - Upper:
ZS44
Frame Headset - Lower:
ZS56
Frame Seatpost:
30.9 mm
Frame Dropper Post Compatible:
Yes (internal)
Frame Seatpost Clamp:
35.0 mm
Frame Derailluer Hanger:
FS2361
Frame Bottom Bracket:
73 mm BSA, threaded
Frame Crankset (Max Ring):
Boost 148 52 mm chainline only (32t max)
Frame Accessory Mounts:
Rear Rack Mounts: Yes. Salsa Post-Lock seatpost collar required, Downtube Accessory Mounts: 1, Top Tube Mounts: Yes, compatible with Salsa EXP Series Top Tube bag.
Frame Bottle Mounts:
2
Frame Front Fender Mounts:
No
Frame Rear Fender Mounts:
No
