2025 Santa Cruz Tallboy FRAME image

2025 Santa Cruz Tallboy FRAME

Santa Cruz
Availability:
Most in stock items ship within 1-3 business days
$3,799.00
(No reviews yet)
Weight:
45.00 LBS
Width:
58.00 (in)
Height:
10.00 (in)
Depth:
32.00 (in)
Current Stock:
Adding to cart… The item has been added
Description

The Tallboy has earned a loyal following amongst those who seek a go-to bike that will hold up to the relentless hammering of power hour rides or riding for all-the-hours. The highly refined VPP™ suspension on the Tallboy combines pedaling efficiency and all-out bump-chomping prowess. If ever there was a gravity riders' XC bike, the Tallboy is it.

  • Carbon CC Frame
  • FOX Float Factory Shock

Specifications

  • Carbon: CC
  • Front (MM): 130
  • Rear (MM): 120
  • Wheel Size: 29
  • Weight (lbs): 2.83
  • Weight (kg): 6.24

01: CC Carbon Frame

02: VPP™ Suspension

03: Flip Chip

04: Glovebox

Click for Geometry

Click for Santa Cruz Bicycles User Manual

Additional Information
Weight:
6.24 lbs / 2.83 kg
Wheel Size:
29
Shock:
FOX Float Factory, 190x45
Headset:
Integrated (IS41/52)
Bottom Bracket Shell:
73mm Threaded
Rear Brake Mount:
PM 180mm
Shock Length:
190mm
Fork Compatibility:
130mm
Fork Offset:
44mm
Max Chainring Size:
36t
Max Tire Clearance:
2.5Inches
Seat Clamp Diameter:
36.4mm
Seat Post Diameter:
31.6mm
Shock Bushing Size Front:
30x8
Shock Bushing Size Rear:
30x8
Shock Stroke:
45mm
Suspension System:
VPP
Material:
Carbon CC
Travel:
120mm
Water Bottle Mounts:
1
