2026 HED Vanquish Pro

The Vanquish Pro Series is HED’s most advanced wheelset, a full carbon, disc brake specific platform engineered for world-class performance and handmade in the U.S.A.

Proven Speed.

Every Vanquish Pro rim is molded and finished by hand in Minnesota. From raw carbon layup to quality control, each wheel passes through multiple stages of inspection to ensure elite-level performance. The result? A fast, stable, rim built on more than 35 years of HED’s aerodynamic leadership.

HED’s Fastest Wheel. Ever.

The Vanquish Pro Series delivers unmatched aerodynamic efficiency. These wheels are designed to cut through the wind and deliver a fast experience from start to finish.

Built for Disc Brakes.

Designed exclusively for disc brakes, each wheel features HED's Pro Centerlock hubs and a tubeless-compatible rim bed. The internal width pairs with today’s wider road tires, reducing rolling resistance while improving grip and control, even in crosswinds.

Additional Feature:

Vanquish Benefits

• Stable crosswind handling characteristics were retained to greater than 70% of typical cycling yaw angles
• 25mm-28mm tires are optimal for performance
• Patented Rim Profiles

Technical Notes:

1. For all types of bicycle wheels, a hard strike on the rim is likely to result in rim damage. At the point of impact, an aluminum rim will dent, and a carbon rim may delaminate - both are unsafe conditions that require rim replacement.

2. Tire pressure = 70psi MAX

3. Freehub Note: *Campagnolo requires a longer lockring to safely secure 10/11/12 speed cassettes to N3W freehubs. Cassette dimensions vary, not all Campy cassettes will work with the N3W body on Hed hubs.

What's In The Box?

• Tubeless Tape (applied from factory)
• Tubeless Valves
• Valve Hole Decals x4 (aero disc only)

Tire Pressure Information:

Max Use:

• 25mm tire: 72 psi / 5 bar
• 28mm tire: 72 psi / 5 bar

Vanquish 45 Pro Specifications:

Vanquish 45 Pro Overview:

• Intended Use: Road Race/All-Road
• Tubeless Compatible
• Inner rim width: 22.4mm
• Optimal Tire Size: 28c

Rim Specs:

• Rim Weight: 415g ± 10g
• Internal Width: 22.4mm
• External Width: 30.9mm
• Depth: 45mm
• Hole Count: 24
• ERD (Includes Washers): 555

Wheelset Build:

Hubs:

• Front Hub: 12x100mm axle. Centerlock
• Bearing: EZO Japan 6902RS
• Rear Hub: 12x142mm axle. Centerlock.
• Freehub: 5 pawl: 8 degree engagement.
• Bearing: EZO Japan 6902RS

Spokes:

• Sapim CX-ray, hooked

Wheelset Weights:

• Front: 701 Grams
• Rear: 798 Grams
• Wheelset: 1499 Grams ± 10g

Vanquish 62 Pro Specifications:

Vanquish 62 Pro Overview:

• Intended Use: Road Race/All-Road
• Tubeless Compatible
• Inner rim width: 22.4mm
• Optimal Tire Size: 28c

Rim Specs:

• Rim Weight: 495g
• Internal Width: 22.4mm
• External Width: 30.9mm
• Depth: 62mm
• Hole Count: 24
• ERD (Includes Washers): 524

Wheelset Build:

Hubs:

• Front Hub: 12x100mm axle. Centerlock
• Bearing: EZO Japan 6902RS
• Rear Hub: 12x142mm axle. Centerlock.
• Freehub: 5 pawl: 8 degree engagement.
• Bearing: EZO Japan 6902RS

Spokes:

• Sapim CX-ray, hooked

Wheelset Weights:

• Front: 750g
• Rear: 923g
• Wheelset: 1673g ± 30g

Vanquish 84 Pro Specifications:

Vanquish 84 Pro Overview:

• Intended Use: Road Race/All-Road / Triathlon
• Tubeless Compatible
• Inner rim width: 22.4mm
• Optimal Tire Size: 28c

Rim Specs:

• Rim Weight: 595g
• Internal Width: 22.4mm
• External Width: 30.9mm
• Depth: 84mm
• Hole Count: 24

Wheelset Build:

Hubs:

• Front Hub: 12x100mm axle. Centerlock
• Bearing: EZO Japan 6902RS
• Rear Hub: 12x142mm axle. Centerlock.
• Freehub: 5 pawl: 8 degree engagement.
• Bearing: EZO Japan 6902RS

Spokes:

• Sapim CX-ray, hooked

Wheelset Weights:

• Front: 850g
• Rear: 960g
• Wheelset: 1810g ± 30g

Vanquish Disc Pro Specifications:

• Wheel Weight:1135g ± 10g
• Hub:HED 5 Pawl PRO
• Bearing Type:6902 2rs Radial

Tire Pressure:

• Max rim pressure 80psi
• Engineering Statement:

"The next generation of Vanquish wheels performed remarkably in the wind tunnel. Across the line we saw improvements in stability while keeping drag to a minimum. Riders can expect a consistent push forward from their new wheels and at the same time count on stable crosswind handling characteristics."
